DFRobot Light & Motor Driver for Python (V1.0)

DFRobot Light & Motor Driver for Python (V1.0) is a versatile PWM driver board designed for precise control of DC motors and LED lighting using Python, PC software, UART communication, or an external potentiometer. Supporting a wide 5V–24V input voltage range and up to 10A output current, it is ideal for automation, robotics, lighting control, embedded systems, and DIY electronics projects.

Features:

1. Supports Python, PC software, UART, and potentiometer control.
2. Ideal for DC motor speed control and LED brightness adjustment.
3. Wide 5V–24V input voltage compatibility.
4. High-current MOSFET output supports loads up to 10A.
5. Single-channel PWM output with adjustable duty cycle.
6. Adjustable PWM frequency for various applications.
7. USB Type-C interface for programming and communication.
8. Supports standard MODBUS communication protocol.
9. Plug-and-play operation with Windows control software.
10. Suitable for automation, robotics, lighting, cooling fans, pumps, and embedded systems.

Specifications:

Parameter	Value
Product Type	PWM Light & Motor Driver Board
Brand	DFRobot
Input Voltage	5V – 24V DC
Maximum Output Current	10A
PWM Channels	1 Channel
PWM Duty Cycle Range	0 – 255
PWM Frequency Range	183Hz – 46875Hz
Output Driver	High-Current MOSFET
Control Methods	Python, PC Software, UART, External Potentiometer
Communication Protocol	MODBUS
USB Interface	USB Type-C
UART Interface	PH2.0 4-Pin
External Potentiometer Interface	2.54mm Pin Header & Terminal Block
Start/Stop Button	1
Mounting Hole Spacing	30 × 50mm
Mounting Hole Diameter	3.1mm
PCB Dimensions	37 × 57mm
Supported Loads	DC Motors, LED Strips, Fans, Pumps
Applications	Motor Speed Control, LED Dimming, Robotics, Automation, Industrial Control, Embedded Systems

Also Check These Out:

ULN2003A Motor Module Stepper Motor Driver

L298N 2A Motor Driver Module

A3967 Stepper Motor Driver Module

L293D Motor Driver Module

Package Includes:

1 × DFRobot Light & Motor Driver for Python (V1.0)
