Large U Beam Aluminium Servo Bracket – U-Shaped Servo Mount

Product Description

The Large U Beam Aluminium Servo Bracket is a lightweight, strong, and versatile mounting bracket designed to fit most standard-sized servo motors. Its large U-shaped beam construction provides a rigid mechanical mounting solution for robotic joints, servo-driven mechanisms, custom structures, and DIY robotics projects.

Manufactured from 2mm hard aluminium, this bracket provides a good balance of strength, durability, and low weight. The U-shaped design offers additional structural support and makes it suitable for connecting and supporting servo motors and other mechanical components in custom robotic assemblies.

Various mounting holes are provided on the bracket to accommodate compatible servo horns, screws, linkages, and other mechanical components. The multiple mounting positions make it easy to create custom mechanisms using standard servo motors and provide flexibility during assembly.

With its strong aluminium construction and approximately 50 g weight, the bracket is suitable for applications where a rigid and dependable servo mounting structure is required.

The black sandblasting oxidation surface finish provides a clean appearance and a durable surface suitable for regular mechanical use.

Features

• Large U-shaped servo mounting bracket
• U-beam aluminium servo bracket
• Designed for most standard-sized servo motors
• Made from 2mm hard aluminium
• Lightweight yet strong construction
• Rigid U-shaped structural design
• Multiple mounting holes
• Suitable for compatible servo horns
• Allows creation of custom servo mechanisms
• Suitable for robotic joints and assemblies
• Ideal for DIY robotics projects
• Suitable for Arduino and microcontroller-based robots
• Useful for custom mechanical structures
• Black sandblasting oxidation finish
• Suitable for robotics, automation, and prototype development

Specifications

Parameter	Specification
Product Type	Large U Beam Aluminium Servo Bracket
Design	Large U-Shaped / U-Beam
Material	2mm Hard Aluminium
Surface Finish	Sandblasting Oxidation
Colour	Black
Weight	Approximately 50 g
Servo Compatibility	Most Standard-Sized Servos
Mounting Type	Mechanical Screw Mounting
Mounting Features	Multiple Holes

Design and Construction

The Large U Beam Aluminium Servo Bracket is manufactured from 2mm hard aluminium to provide a strong and rigid mounting structure while maintaining a relatively lightweight construction.

Its U-shaped beam design provides additional structural rigidity compared with a flat mounting plate, making it suitable for applications where the bracket needs to support a servo motor or form part of a larger mechanical assembly.

Multiple mounting holes are provided throughout the bracket, giving users flexibility when positioning servo motors, servo horns, linkages, brackets, and other components. This makes the bracket suitable for building custom mechanisms according to the requirements of individual projects.

The bracket features a black sandblasting oxidation surface finish that provides a clean and professional appearance.

Working Principle

The bracket functions as a mechanical support and mounting interface for a standard-sized servo motor and other components.

The servo motor can be secured to the U-shaped bracket using suitable mounting screws. Compatible servo horns, linkages, or other mechanical components can then be connected through the available mounting holes.

When the servo rotates, the attached servo horn or linkage transfers the servo’s movement to the connected mechanism. The rigid U-beam structure helps maintain a stable mechanical connection during operation.

The bracket itself is a passive mechanical component and does not require electrical power.

Applications

• DIY robotics projects
• Arduino robot projects
• Servo-controlled mechanisms
• Robotic arms
• Robotic joints
• Robot legs
• Walking robots
• Humanoid robots
• Biped robots
• Custom servo mechanisms
• Servo motor mounting
• Mechanical linkages
• Multi-axis robotic assemblies
• Automation projects
• RC robotics
• Educational robotics
• Custom robot structures
• Mechanical prototype development
• Servo-driven machines
• Embedded robotics systems

Package Includes

• 1 × Large U Beam Aluminium Servo Bracket

Product Disclaimer

Product images are shown for illustrative and representational purposes only. The actual product may vary slightly in colour, dimensions, surface finish, hole positioning, slot dimensions, or appearance depending on the manufacturing batch.

Servo motor, servo horn, screws, linkages, robot parts, and other components shown in product images are not included unless specifically mentioned in the package contents.

Compatibility with a particular servo depends on the servo’s physical dimensions and mounting-hole arrangement. Please verify the dimensions and mounting pattern before installation.
