UART TTL Serial MP3 Music Player Module

Product Description

The UART MP3 Module is a compact audio playback module based on the YX5300/JL high-quality MP3 audio chip, designed to add MP3 and WAV playback functionality to electronic projects. It features an onboard TF card slot for storing audio files and can be controlled through a UART serial interface.

The module allows a microcontroller to send commands for song selection, volume adjustment, playback control, and play-mode selection. It is compatible with popular platforms such as Arduino, AVR, ARM, and PIC, making it suitable for a wide range of embedded and DIY applications.

The module supports sampling frequencies from 8kHz to 48kHz and provides a simple way to integrate audio playback into interactive projects, voice systems, alarms, and electronic devices. Depending on stock availability, the module may use a YX5300 or JL IC.

Features

• Compact UART MP3 player module
• YX5300/JL MP3 audio chip
• Supports MP3 and WAV audio
• 8kHz–48kHz sampling frequency
• Onboard TF card slot
• UART serial control
• Command-based playback control
• Adjustable volume
• Song selection and switching
• Multiple playback modes
• Compatible with Arduino, AVR, ARM, and PIC
• Supports USB-to-UART debugging
• Easy integration into electronic projects

Specifications

Parameter	Specification
Product Type	UART MP3 Module
Audio Chip	YX5300 / JL
Supported Formats	MP3 / WAV
Sampling Frequency	8kHz–48kHz
Storage	TF Card
Control Interface	UART
Debug Interface	USB-to-UART
Compatible Platforms	Arduino / AVR / ARM / PIC
Control Functions	Playback / Song / Volume / Mode

Working Principle

Audio files are stored on a TF card and accessed by the module during playback. A connected microcontroller communicates with the module through the UART interface and sends commands to select songs, control playback, adjust volume, and change playback modes.

The module processes the selected audio file through its onboard MP3 audio chip and produces the corresponding audio output for connection to a suitable audio system.

Applications

• Arduino audio projects
• Voice prompt systems
• Interactive electronic projects
• Audio alarms
• Automated announcements
• Educational projects
• Embedded audio systems
• Interactive installations
• DIY MP3 players
• Microcontroller-based audio applications

Package Includes

• 1 × UART MP3 Module

Product Disclaimer

The module may be supplied with either a YX5300 or JL IC depending on stock availability. Both versions provide the intended UART-controlled MP3 playback functionality.

Product images are for representation only. The actual product may vary slightly in colour, appearance, PCB layout, or hardware components depending on the manufacturing batch.
