6N137 High Speed Optocoupler IC - DIP-8 Package

6N137 High Speed Optocoupler IC - DIP-8 Package is a high-speed optically isolated logic interface IC designed for fast digital signal transmission while providing excellent electrical isolation between input and output circuits. It features a high-speed photodetector with a logic gate output, making it ideal for microcontroller interfacing, industrial automation, communication systems, switching power supplies, and digital isolation applications. The DIP-8 package allows for easy through-hole mounting and prototyping.

Features:

1. High-Speed Optocoupler
2. Logic Gate Output
3. High Data Transmission Rate
4. Excellent Electrical Isolation
5. Low Power Consumption
6. High Common Mode Noise Immunity
7. TTL and CMOS Compatible Output
8. Open Collector Output
9. Wide Operating Voltage Range
10. Fast Switching Performance
11. Reliable Signal Isolation
12. DIP-8 Through-Hole Package
13. Suitable for Microcontroller Interfacing
14. Ideal for Industrial Automation & Communication Systems
15. RoHS Compliant

Specifications:

Parameter	Value
Product Type	High-Speed Optocoupler IC
Model	6N137
Package	DIP-8
Isolation Voltage	5000Vrms
Data Rate	Up to 1Mbps
Output Type	Open Collector Logic Output
Input Type	Infrared LED
Supply Voltage (VCC)	4.5V to 5.5V
Forward LED Current	10mA (Typical)
Propagation Delay	0.5µs (Typical)
Common Mode Rejection (CMR)	10kV/µs (Typical)
Operating Temperature	-40°C to +85°C
Mounting Type	Through Hole
Applications	Digital Signal Isolation, Microcontroller Interfaces, PLCs, Industrial Control, SMPS Feedback, Communication Systems
RoHS Compliance	Yes

Pin Configuration:

Pin	Function
1	Anode
2	Cathode
3	NC
4	GND
5	VO (Output)
6	VCC
7	VE (Output Enable)
8	NC
